characteristic:
1) Tolerance of parallel line of the cut plate: ± 0.2mm/m
Diagonal tolerance of the cut sheet: ± 0.25mm/m
2) Edge/surface quality:
The cutting surface is smooth: there is no scratch, jamming, crushing and other basic problems on the plate surface in normal operation
3) Other auxiliary devices:
Effective safety protection measures: reduce the risk of scrap of plates during operation
4) With rounded corner function
5) Tool life (the cutting thickness is 50 mm, and it can be grinded once every 2000 meters. The second time is 1800 meters, and it can be grinded 6-8 times)
(The cutting thickness is 30mm. Grind once for 3000m. Grind for 6-8 times for 2700m from the second time)
6) Cutting loss: tool thickness 2.4mm, loss 2.4mm; Tool thickness 3.0 mm, loss 3.0 (and so on)
7) Tooth material: diamond,
8) Within the service life of the tool, all cutting plates shall be free of curling, copper wire, copper chips and other undesirable phenomena
9) Two additional cutters can be used for recycling
10) The equipment is equipped with leakage protection switch
11) The float design of the worktable prevents the board from scratching
12) With code scanning function
Main technical parameters
Sawing width: 2500mm
Sawing length: 2500mm
Maximum sawing thickness 50mm
Diameter of main saw blade: Φ 305mm
Shaft diameter of main saw blade: Φ 25.4mm
Rotation speed of main saw blade: 3600-4000 rpm
Main shaft power: 12Kw
Feeding power: 1.5Kw
Cutting speed: 0~10m/min (the cutting speed of circuit board is 4m/min~5m/min)
Saw block power: 3Kw
Moving speed of saw block: 20m/min
Air flotation platform power: 0.75Kw+0.75Kw+3Kw
Total power: 21Kw
Service air pressure: 5-7Kg/cm2
Height of workbench from the ground: 900 ± 50mm
Net weight: 4500Kg
Machine size (L * W * H): 5658 * 5592 * 1630mm
Air volume:>35-65CMM
Control system
High performance touch screen, clear and reliable, easy to operate
Programmed control: the operation interface is in Chinese/English and easy to operate
Security system: alarm system and emergency stop device.
Group continuous cutting can be set
Save 200 sets of cutting parameters
Automatic oil filling system
